Item name: 371W 17R hybrid moving head lights
-
Item No.: LD-MH-371-BSW-CMY
-
Channel mode: 21chs/25chs
-
Input voltage: AC110-240V, 50/60Hz
-
Rated power consumption: 550W
-
Light source model: OSRAM 371W 17R
-
Light source life: 1500 hours
-
Advanced optical system, clear pattern, sharp beam and clear edge
-
Zoom angle: 4°～37°
-
Fixed gobo wheel: 16 gobos + white
-
Rotating gobo wheel: 9 gobos + white (can be customized and replaced), the diameter of the rotating gobo is 14.9mm, the effective diameter is 11mm, and the thickness of the gobo is 1.1mm
-
Effect Wheel: can be used alone, can be used in combination with other wheels
-
Color wheel: 11 shortcut color + CTO color temperature + white + CMY
-
Rotating prism wheel: 8 prisms + straight 6 prisms + atomizing mirror (prisms can be superimposed)
-
Display: LCD color LCD touch screen
-
Control method: support DMX512, RDM, auto run
-
Supports dialing the address code when the power is off, and can be used as a software to upgrade the external interface
-
X Axis: 540°, resolution 8/16Bit
-
Y Axis : 270°, resolution 8/16Bit
-
XY axis with automatic error correction system
-
Adopting magnetoelectric positioning system, using magnetic devices to replace the traditional Hall positioning system
-
Unaffected by the interference of oily smoke, dust, and natural light, with higher accuracy and reliable performance
-
Signal input port: 3-pin
-
Product size: 440x310x680 mm
-
Flight case size: 930x520x910 mm
-
Carton size: 540x450x650 mm
-
Net weight: 20 KG
-
Gross weight: 25 KG (carton packaging)
Tag：371W 17R hybrid moving head lights
...
